Product Type:
Contactor
Coil Voltage:
400 V
Number of Poles:
4
Contact Voltage:
690V
Contact Current:
10A
Series:
CA2KN
Function:
Control Relay
Mount Type:
DIN Rail
Normal State Configuration:
2 NO/2 NC
Number of Auxiliary Contacts:
4
Auxiliary Contact Configuration:
2 NO/2 NC
Terminal Type:
Screw Clamp
Contactor Application:
Control Circuit
Control Circuit Voltage Uc:
400 V
Minimum Operating Temperature:
-25°C
Maximum Operating Temperature:
50°C
Standards/Approvals:
CB scheme, CCC, CE, CSA, CSA C22.2 No 60947-4-1, EAC, EN/IEC 60947-4-1, GB/T 14048.4, JIS C8201-4-1, REACH, RoHS, UKCA, UL, UL 60947-4-1
Length:
58mm
Depth:
57mm
Width:
45 mm
Better World Product:
Yes
Pole and Throw Configuration:
4
