Coil Voltage:
24 V
Product Type:
Contactor
Number of Poles:
5
Contact Voltage:
690V
Contact Current:
10A
Series:
CAD
Mount Type:
Rail, Plate
Function:
Control Relay
Normal State Configuration:
3 NO/2 NC
Auxiliary Contact Configuration:
3 NO/2 NC
Number of Auxiliary Contacts:
5
Terminal Type:
Spring Terminal
Minimum Operating Temperature:
-5°C
Control Circuit Voltage Uc:
24 V
Contactor Application:
Control Circuit
Maximum Operating Temperature:
60°C
Width:
45 mm
Depth:
95mm
Standards/Approvals:
UKCA, UL 60947-5-1, UL, RoHS, REACH, JIS C8201-5-1, GB/T 14048.5, EN/IEC 60947-5-1, EAC, CSA C22.2 No 60947-5-1, CSA, CE, CCC, CB scheme
Length:
99mm
Better World Product:
Yes
Pole and Throw Configuration:
5
