Coil Voltage:
12V dc
Contact Configuration:
DPDT
Mounting Type:
PCB Mount
Maximum Switching Current AC:
2 A
Maximum Switching Current DC:
2 A
Maximum Switching Voltage AC:
250V
Maximum Switching Voltage DC:
220V
Series:
EC2
Maximum Switching Power DC:
60 W
Length:
15mm
Latching:
Yes
Depth:
7.5mm
Height:
9.4mm
Dimensions:
15 x 7.5 x 9.4mm
Terminal Type:
Through Hole
Switching Current:
2A
Application:
Electronic Switching Systems, PBX, Telecommunications, Terminal Equipment
Number of Poles:
2
Operating Temperature Range:
-40 → +85°C
Features:
Compact and Lightweight, Low Magnetic Interference, Low Power Consumption
Contact Material:
Gold Plated
Standards Met:
CSA, UL Recognized E73266
Relay Switching Classification:
Latching Relay
Maximum Operating Temperature:
+85°C
Isolation Coil To Contact:
1kV ac
Minimum Operating Temperature:
-40°C
Coil Power:
140mW
Maximum Switching Power AC:
125VA
Coil Resistance:
1028Ω
